Pig slat

Groove width 18 or 20 mm
Fill slats available for flexible grid division
Good manure drainage thanks to unequal beams
Grids with less than 15% drainage available on demand
Grids with a thickness of 12 cm and a width of 100 cm are available for large spans

STANDARD PIG GRID

ARTICLE	L (cm)	W (cm)	H (cm)	G (mm)	WEIGHT (kg)
4070	70	50	10	18	52
4075	75	50	10	18	56
4080	80	50	10	18	59
4090	90	50	10	18	66
4095	95	50	10	18	70
4100	100	50	10	18/20	73
4110	110	50	10	18	81
4120	120	50	10	18	89
4125	125	50	10	18	92
4140	140	50	10	18/20	101
4150	150	50	10	18/20	110
4160	160	50	10	18/20	118
4170	170	50	10	18/20	126
4175	175	50	10	18/20	130
4195	195	50	10	18/20	144
4200	200	50	10	18/20	148
4210	210	50	10	18	155
4220	220	50	10	18/20	162
4225	225	50	10	18/20	167
4235	235	50	10	18	174
4240	240	50	10	18	177
4245	245	50	10	18	181
4250	250	50	10	18	185
4260	260	50	10	18	193
4265	265	50	10	18	197

FILL SLATS

ARTICLE	L (cm)	W (cm)	H (cm)	WEIGHT (kg)
4080/25	80	25	10	30
4100/25	100	25	10	37
4150/25	150	25	10	56
4170/25	170	25	10	64
4175/25	175	25	10	65
4195/25	195	25	10	73
4200/25	200	25	10	74

ARTICLE	L (cm)	W (cm)	H (cm)	WEIGHT (kg)
4150/20	150	20	10	51
4170/20	170	20	10	58
4175/20	175	20	10	59

REINFORCED PIG GRID

ARTICLE	L (cm)	W (cm)	H (cm)	WEIGHT (kg)
60250	250	100	12	391
60275	275	100	12	431
60300	300	100	12	471

CONCRETE TYPE	CONCRETE QUALITY	STEEL QUALITY	CONCRETE COVER	SURFACE FINISH
Earth dry	C45/55	DE500BS	25 mm	Regrinded with fine quartz sand
